Composition And Characteristics Of Flake Ice Machine Evaporator

The composition of the evaporator

The evaporator of the ice machine is driven by the ice blade, sprinkler tray, main shaft, and water tray, and is slowly rotated counterclockwise under the drive of the reducer. Water enters the water distribution tray from the water inlet of the ice machine evaporator, and through the sprinkler pipe, the water is evenly sprinkled on the icing surface to form a water film; the water film exchanges heat with the refrigerant in the refrigerant flow channel, and the temperature drops rapidly , A thin layer of ice is formed on the icing surface, and under the extrusion of the skates, it breaks into flakes of ice and falls into the ice storage from the ice outlet. Part of the unfrozen water returns to the cold water tank from the water return port through the water receiving tray, and circulates through the cold water circulation pump.

Flake ice machines have been widely used in aquatic products, food, supermarkets, dairy products, medicine, chemistry, vegetable preservation and transportation, marine fishing and other industries. With the development of society and the continuous improvement of people's production levels, the industries using ice are becoming more and more extensive. The quality requirements for ice are getting higher and higher. The requirements for "high performance", "low failure rate" and "hygiene" of ice machines are becoming more and more urgent.

application

1. Application in aquatic product processing: flake ice can reduce the temperature of processing medium, cleaning water, and aquatic products, prevent bacteria from growing, and keep aquatic products fresh during processing.

2. Application in meat product processing: mix flake ice that meets hygienic standards into meat and stir. In order to achieve the purpose of cooling and keeping fresh.

3. Application in food processing: For example, when stirring or second creaming in bread production, use flake ice to quickly cool down to prevent fermentation.

4. Application in supermarkets and aquatic product markets: for the freshness preservation of aquatic products such as placement, display, and packaging

5. Application in vegetable processing: Flake ice is used in the harvesting and processing of agricultural products and vegetables to reduce the metabolism of agricultural products and the growth rate of bacteria. Extend the shelf life of agricultural products and vegetables.

6. Application in long-distance transportation: Ocean fishing, vegetable transportation and other products that need to be cooled and kept fresh are more and more widely used in long-distance transportation to cool down and keep fresh with flake ice.

7. It is also widely used in laboratories, pharmaceuticals, chemicals, artificial ski resorts and other industries.

⒏Application in concrete engineering: When concrete is poured in a large area in hot season, the pouring temperature of concrete must be effectively and reasonably controlled. Flake ice + cold water mixing is the most effective way.

Flake ice has obvious advantages compared with traditional types of ice bricks (big ice) and snowflake ice. It is dry, not easy to agglomerate, has good fluidity, good hygiene, large contact area with fresh-keeping products, and is not easy to damage fresh-keeping products. It is the product of choice to replace other types of ice in many industries. and have:

1. High ice-making efficiency and low cooling loss:

The automatic flake ice machine adopts the latest vertical internal spiral cutter ice-cutting evaporator. When making ice, the water diversion device inside the ice bucket will evenly distribute the water to the inner wall of the ice bucket to freeze quickly. The ice knife cuts the ice and falls, so that the surface of the evaporator is fully utilized, and the efficiency of the ice machine is improved.

2. The quality of borneol is good, dry and not sticky:

The thickness of the flake ice produced by the vertical evaporator of the automatic flake ice machine is 1-2 mm, which is dry and irregular scaly ice with good fluidity. 3. Simple structure, small footprint

features

1. Direct low temperature, low ice temperature, can reach below -8°.

2. The ice is dry and clean, beautiful in shape, not easy to form a block, good in fluidity, hygienic and convenient.

3. The flaky structure, so it has a large contact area with the refrigerated product, and the cooling effect is excellent.

4. Flake ice has no sharp edges and corners, will not damage the surface of refrigerated products, and is very convenient for storage and transportation.

5. The thickness of the ice can reach 1mm-2mm, and there is no need for an ice crusher, and it can be used at any time.

6. The surface area can reach more than 1500 square meters per ton.
